Carbide Inserts for Shop Fox Jointers Planers with Spiral Cutterheads 14.17x14.17x2mm
Carbide Inserts for Shop Fox Jointers Planers with Spiral Cutterheads 14.17x14.17x2mm - 1 Pc is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Payment & Security
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Trusted Delivery
- Description
- Reviews
Same as Shop Fox D4018 carbide inserts, the 14.17 x 14.17 x 2mm carbide indexable insert fits the following Shop Fox machines manufactured before March 2015. (After see D3379)
Including
W1741S 8" Jointer with Adjustable Beds and Spiral Cutterhead 32 inserts
W1742S 3 HP 15" Planer Cast Iron Wings & Mobile Base and Spiral Cutterhead 98 inserts
W1744S 12" Heavy-Duty Jointer w/Adjustable Beds and Spiral Cutterhead 60 inserts
W1754S 20" Planer with Built in Mobile Base and Spiral Cutterhead 74 inserts
W1755S 6" Parallelogram Jointer with Spiral Cutterhead 40 inserts
South Bend Planers:
SB1108 15" Planer with Helical Cutterhead 52 inserts
SB1109 20" Planer with Helical Cutterhead 92 inserts
FindBuyTool indexable insert knives are all precision manufactured from top-quality tungsten carbide, allowing for
- Outstanding wear resistance, corrosion resistance, oxidation resistance.
- Use on All kinds of wood, plywood, MDF, etc.
- Easy installation and replacement
- Perfect thickness consistency.
- Super durability and long-lasting razor-sharp edges
- Eliminating tear-outs and marks on the board.
Other carbide insert knives you may need:
- Byrd Shelix cutter head replacement blades
- Powermatic/Jet helical planer/jointer replacement inserts
- 14x14x2mm carbide inserts for Grizzly machines
- 14.3x14.3x2mm double-sided carbide inserts
- 13.8x13.8x2.5mm carbide inserts for Felder/Format/Hammer machines
- 15x15x2.5mm-R150 carbide insert
- 15x15x2.5mm-R150-4R0.5 carbide insert
Technical information
Technical information
Cutting Edges | 4-Edge |
Length | 14.17 |
Width | 14.17 |
Thickness | 2 |
Cutting bevel | 30 |
Shape | Square |
Applications
Applications
- Wood
SHIPPING DIAMETER
SHIPPING DIAMETER
- UNIT
- Pcs
- Net Weight
- 1.3g
- Package
- in Plastic Box
- Package Size
- 65X20X20mm
