24 Degree Horse Nose Router Bit
- Description
- Reviews
The low-angle bevel edge bit without bearing is designed for chamfering or softening edges. It will cut a 24°(or 66°) angle on your workpiece, such as the table edge. It can also be used to create miter joints for a box. We also offer the edge bevel router bits of other angles, including 10°, 12°, 15°, and 25°&30°.
For better safety, we suggest using our chamfer horse nose router bits in a router table or a routing machine, instead of a handheld router. Pay attention to the RPM and feed speed.
- We supply a full line of industrial-grade router bits.
- For our European-standard precision, premium carbide tips supplied by Ceratizit
- Adopting advanced welding technology, you can rely on our quality.
- The guide bearing can guide the bit better along with the workpiece, producing a smooth and precise cut.
Technical information
Technical information
| Shank Size x 2B(In.) | D (mm) | α | H (mm) | B (mm) | Material |
|---|---|---|---|---|---|
| 1/2 x1/2 | 25.7 | 24° | 7.58 | 6.35 | Tungsten Carbide |
| 1/2 x5/8 | 28.9 | 24° | 8.3 | 7.96 | Tungsten Carbide |
| 1/2 x 3/4 | 32.04 | 24° | 10.58 | 9.52 | Tungsten Carbide |
| 1/2 x 7/8 | 35.2 | 24° | 11.29 | 11.1 | Tungsten Carbide |
| 1/2x 1 | 38.4 | 24° | 12 | 12.7 | Tungsten Carbide |
| 1/2 x1-1/8 | 41.57 | 24° | 13.49 | 14.28 | Tungsten Carbide |
| 1/2x1-1/4 | 44.75 | 24° | 14.2 | 15.87 | Tungsten Carbide |
| 1/2 x1-1/2 | 51.1 | 24° | 15.62 | 19.05 | Tungsten Carbide |
| 1/2x1-5/8 | 54.27 | 24° | 16.32 | 20.63 | Tungsten Carbide |
| 1/2x1-3/4 | 57.45 | 24° | 17.02 | 22.2 | Tungsten Carbide |
| 1/2x2 | 63.8 | 24° | 18.44 | 25.4 | Tungsten Carbide |
Applications
Applications
- Wood
Machine
Machine
- CNC Router
- Fixed Base Router
- Plunge Router
- Bench Top Router Table
SHIPPING DIAMETER
SHIPPING DIAMETER
- UNIT
- Pcs
- Net Weight
- 50
- Package
- In Plastic Box
- Package Size
- 95 x 18 x 18mm
